| Slope 4 pH | Display | Cal 7pH | TEMP | FUNCTION |
| SLOPE CONTROL | This Control varies the gain adjustment from 80% to 120% .
This adjustment is neccessary when output of the electrode is different from the standard output. This control is used for calibration with second buffer solution. |
| DIGITAL DISPALY | A 31/2 Digital display that reads uptio +-1999
The decimal point appears automatically in the pH mode Negative(-) indicator is displayed when negative milivolts are applied at the input in mv mode. |
| CALIBRATE CONTROL | The control sets the digital readout to the value of the calibration buffer that is used. Calibrate controloperates inboth modes (ph or mv). |
| TEMPERATURE DEGREE(C) | This Slop Compensates for the slop versus temperature. Characteristics ofelectrode and operates in the pH mode only |
|
pH mv |
0 to14 pH +-1999 |
|
Reszolution mv Resolution |
0.01pH 1 |
|
Repeatability mv Repeatability |
+-0.01pH +-1 |
|
Accuracy mv |
+-0.01pH +-1 Digit) pH +-0.14% or fs or+-2 |
| input impedence | >1013ohm |
| Auto Temp Compensation | 0 to 100 degree celesius |
| Operation Temp Range | 100c to 50 degreec |
| Display |
3*(1/2) digit bright red Sven Segment FND Display with automatic polarity and decimal point indication. |
| Power | 230V +-10% AC, 50/cs |
