Hand Operated Sieve Shaker

Hand Operated Sieve Shaker Manufacturers
Hand Operated Sieve Shaker is light, portable but sturdy equipment suitable for bench mounting. The Hand Operated Sieve Shaker is supplied without sieves, lid and receiver. We are named amidst the famous Hand Operated Sieve Shaker, Exporters, and Suppliers in India. The Hand Operated Sieve Shaker can be availed from us at the most competitive prices.

Details

  • The side to side movement to the carrier, which can take up to 7 sieves of 15 cm or 20 cm diameters, is through a train of gears operated by a hand wheel. A heavy fly wheel ensures smooth operation.
  • Motorized : Carries up to 7 sieves of 20 cm diameter.
  • The shaker is driven by a 1/4 hp. electric motor through a reduction gear.
  • The sieve table does not rotate but is inclined from the vertical axis and the direction changes progressively in the clockwise direction.
  • By removal of a stop-pin fixed to below the table, the shaker can have a rotatory motion. In addition to the gyratory motion of the table, there is an upward and downward movement ensuring that each square cm of the sieve is utilized.
  • The whole gear mechanism runs in an oil bath. Suitable for operation on 230 volts, 50 cycles, single phase, AC supply- Supplied without sieves, lid and receiver and time switch.
  • Optional : Adaptor for 30cm diameter sieves, time switch, 0-60, min. graduations
